高效精密CNC车床-TNC-08N
MENU
| Capacity | |
|---|---|
| Swing over Bed | 400 mm |
| Swing over saddle | 200 mm |
| Distance between centers | 400 mm |
| Bed width | 320 mm |
| Hydraulic chuck | 8＂ |
| Bar capacity | Ø 52 mm |
| Bed slant angle | 20° |
| Cutting diameter / length | Ø 200 / 480 mm |
| Spindle | |
| Spindle nose | A2-6 |
| Spindle hole | 60 mm |
| Spindle speeds | 100-4000 rpm |
| Spindle motor | 10HP |
| Spindle OD diameter | Ø 100 mm |
| Turret | |
| Turret type | Hydraulic |
| Tool station | 8 |
| Tool holder size | Ø32 mm, Ø25 mm |
| X travel | 320 mm |
| Z travel | 560 mm |
| Rapid travel | 12 M/Min. |
| Tailstock | |
| Tailstock travel | 360 mm |
| Quill travel | 100 mm |
| Quill taper | MT4 |
| Tailstock diameter | Ø 53 mm |
※ 规格如有变更，恕不另行通知。
