Boring Machine-CBA-110R2
Boring Machine
CBA-110R2
- High accuracy, high quality, high rigidity
- Fully automatic operation
- Spindle made in house
- Ideal for fabricating molds
- High efficiency
MENU
| Travel | |
|---|---|
| Work table travel X axis(Horizontal) | 2000 mm |
| Spindle travel Y axis(Vertical) | 1800 mm |
| Work table travel Z axis(Vertical) | 1300 mm |
| Spindle travel W axis | 400 mm |
| Spindle | |
| Spindle diameter | Dia. 110 mm |
| Main motor (con/30min) | 22 / 26 kw |
| Spindle speed (Max.) | 3000 rpm |
| Spindle tapper | ISO 50 / BT-50 |
| Spindle end diameter | Dia. 215 mm |
| Max. spindle torque | 912 Nm |
| Rotary Table | |
| Table dimension | 1400 x 1600 mm |
| T-slot | 22 x 9 mm |
| Max. loading weight | 8500 kg |
| Index | 0.001° degree |
| Max. rotation diameter | 2126mm |
| Table rotation speed | 0.8 rpm |
| Feed | |
| Feed rate(X/Y/Z) | 1 – 5000 mm / min |
| Feed rate(W axis) | 1 – 3000 mm / min |
| Rapid feed(XYZW axis) | XYZ axis = 10000 / W axis = 3000 mm / min |
| Miscellaneous | |
| Machine weight | 25000 kg |
| Power capacity | 80 |
| Machine dimension (L x W x H) | 5500 x 8700 x 4540 mm |
| Controller | Fanuc / Siemens / Heidenhain |
※ The specifications are subject to change without prior notice.
Features
Fully automatic operation
Spindle made in house
Ideal for fabricating molds
High efficiency
Spindle made in house
Ideal for fabricating molds
High efficiency
